| | Joined: Mar 2012 Posts: 82 Member | | Member Joined: Mar 2012 Posts: 82 | I need a alternator for 1967 150, 12v,50A. Three bolt mount.
Thanks,
George
cessna 150H / 15067528
| | | | | Joined: Mar 2004 Posts: 12,760 Member/10,000+ posts! | | Member/10,000+ posts! Joined: Mar 2004 Posts: 12,760 |
Message sent from a rotary pay phone... Bengie [ Linked Image]
| | | | | Joined: Feb 2004 Posts: 5,975 Member/5000+posts! | | Member/5000+posts! Joined: Feb 2004 Posts: 5,975 | | | | | | Joined: Dec 2003 Posts: 25,453 Likes: 1006 Member/25,000 posts | | Member/25,000 posts Joined: Dec 2003 Posts: 25,453 Likes: 1006 | I need a alternator for 1967 150, 12v,50A.
I have a spare 24V alternator. How 'bout double the power at half the 12V cost?  | | | | | Joined: May 2009 Posts: 4,533 Likes: 370 Member/2500+posts | | Member/2500+posts Joined: May 2009 Posts: 4,533 Likes: 370 | The 1963-1969 parts manual shows the alternator (Cessna 611501-0202 for 150 S/N 15064533 and up, which includes the 1967 model) as being rated at 60 amps, not 50.
Roy
States where I've landed my 150 ![[Linked Image from eznec.com]](https://eznec.com/images/States_Landed_In.jpg) | | | | | Joined: Mar 2012 Posts: 82 Member | | Member Joined: Mar 2012 Posts: 82 | The tag on my alternator says 14v/50amp. It might not be the original. I have since found a 15v/60amp overhauled alternator.
cessna 150H / 15067528
| | | | | Joined: Jun 2011 Posts: 19,230 Likes: 2358 Member/15,000 posts | | Member/15,000 posts Joined: Jun 2011 Posts: 19,230 Likes: 2358 | 60 amp alternator to match the 60 amp breaker - right? | | | | | Joined: May 2009 Posts: 4,533 Likes: 370 Member/2500+posts | | Member/2500+posts Joined: May 2009 Posts: 4,533 Likes: 370 | Dunno. Could just be a peak vs continuous output spec for the same alternator. But you wouldn't want to use a 60 amp fuse with an alternator not rated for 60 amps continuous. Fuses are typically specified to pass the rated current for an indefinite period of time, only blowing when the current exceeds the rated current. That is, a 60 amp fuse will never blow when passing 60 amps, even continuously. The time it takes to blow depends on the type of fuse and how great the overload is, but there must be an overload beyond the rated current for it to blow.
Roy
States where I've landed my 150 | | | | | Joined: Dec 2003 Posts: 14,797 Likes: 551 Member/10,000+ posts! | | Member/10,000+ posts! Joined: Dec 2003 Posts: 14,797 Likes: 551 | The OEM (Cessna) alternator is 60 amp. But the aftermarket alternators from PlanePower or JASCO are 50 amp. Perhaps you have one of those? See if there's an STC for an alternator conversion in your plane's paperwork.
If I recall, the JASCO alternator can only be rebuilt by JASCO (they withold the parts and data). I don't know about PlanePower's rebuildability, but they use a Nippondenso alternator so I would *think* it's easily rebuilt.
-Kirk Wennerstrom
President, Cessna 150-152 Fly-In Foundation
1976 Cessna Cardinal RG N7556V
Hangar D1, Bridgeport, CT KBDR
| | | | | Joined: Jun 2006 Posts: 1,024 Likes: 1 Member/1000+posts | | Member/1000+posts Joined: Jun 2006 Posts: 1,024 Likes: 1 | Start with the IPC or STC. Matching a wrong part with another wrong part is ... well wrong!
John
150-61401
C-FUUE
| | |
|
|
